STUD

  • AVAILABLE IN A VARIETY OF STRENGTH RATINGS AND GRADES
  • CAN BE SUPPLIED COMPLETE WITH NUTS AND WASHERS
  • BOLTS MAY BE FULL OR HALF THREADED
  • THREADS MAY BE CUT OR ROLLED AS REQUIRED
  • THREADS MAY BE AS PER UNC, UNF, BSW, METRIC SERIES, ETC. AS REQUIRED
  • PRODUCTS HOT DIP GALVANIZED AS PER BS EN ISO 1461 OR EQUIVALENT INTERNATIONAL STANDARDS
  • PRODUCTS MANUFACTURED AS PER ALL ESTABLISHED INTERNATIONAL STANDARDS SUCH AS ASTM , ANSI, BSI (BS) , BS EN, ISO, IEC, EN, BIS (IS) , DIN, SABS (SANS), NFC, ETC.
  • PRODUCTS CAN BE MANUFACTURED OR CUSTOMISED AS PER CLIENT REQUIREMENT
PRODUCT CODE DIMENSION
BOLT DIA LENGTH THREAD LENGTH NO.OF NUTS
MM IN MM IN
AO-THD-ROD-01 - '3/8 100 - 1000 '4 - 40 FULL THREAD OR AS PER REQUIREMENT 4
AO-THD-ROD-02 12 '1/2 100 - 1000 '4 - 40 4
AO-THD-ROD-03 14 '- 100 - 1000 '4 - 40 4
AO-THD-ROD-04 16 '5/8 250 - 1100 '10 - 44 4
AO-THD-ROD-05 18 '- 250 - 1100 '10 - 44 4
AO-THD-ROD-06 20 '- 250 - 1100 '10 - 44 4
AO-THD-ROD-07 - '3/4 250 - 1100 '10 - 44 4
AO-THD-ROD-08 22 '7/8 250 - 1100 '10 - 44 4
AO-THD-ROD-09 24 '- 250 - 1100 '10 - 44 4
AO-THD-ROD-10 25 1 250 - 1100 '10 - 44 4
AO-THD-ROD-11 30   250 - 1100 '10 - 44 4
AO-THD-ROD-12 32 '1-1/4 250 - 1100 '10 - 44 4
