POLE CLAMP - ADJUSTABLE / POLE BAND
- USED TO ATTACH STRUCTURE, EQUIPMENT AND FITTINGS TO POLES
- AVAILABLE IN A VARIETY OF STRENGTH RATINGS AND GRADES
- CAN BE USED WITH ALL TYPES OF POLES, INCLUDING STEEL POLE, RCC, PSC AND WOODEN
- CAN BE MANUFACTURED FOR ALL POLE SIZES AND DIAMETERS
- CAN BE SUPPLIED WITH CROSSARMS AND FITTINGS
- PRODUCTS HOT DIP GALVANIZED AS PER BS EN ISO 1461 OR EQUIVALENT INTERNATIONAL STANDARDS
- PRODUCTS MANUFACTURED AS PER ALL ESTABLISHED INTERNATIONAL STANDARDS SUCH AS ASTM , ANSI, BSI (BS) , BS EN, ISO, IEC, EN, BIS (IS) , DIN, SABS (SANS), NFC, ETC.
- PRODUCTS CAN BE MANUFACTURED OR CUSTOMISED AS PER CLIENT REQUIREMENT
| PRODUCT CODE |
DIMENSION |
| POLE DIA |
FLAT SIZE |
DOUBLE ARMING BOLT SIZE |
| MM |
IN |
WIDTH (MM) |
THICKNESS (MM) |
MM |
| AO-PC-ADJ-01 |
152 - 292 |
'6.00 - 11.50 |
100 |
6 |
20 |
| AO-PC-ADJ-02 |
178 - 241 |
'7.00 - 9.50 |
100 |
6 |
20 |
| AO-PC-ADJ-03 |
203 - 279 |
'8.00 - 11.00 |
100 |
6 |
20 |
| AO-PC-ADJ-04 |
241 - 305 |
'9.50 - 12.00 |
100 |
6 |
20 |
| AO-PC-ADJ-05 |
241 - 355 |
'9.50 - 14.00 |
100 |
6 |
20 |
| AO-PC-ADJ-06 |
241 - 406 |
'9.50 - 16.00 |
100 |
6 |
20 |
| AO-PC-ADJ-07 |
305 - 406 |
'12.00 - 16.00 |
100 |
6 |
20 |
