POLE CLAMP - 2A
- USED TO ATTACH STRUCTURE, EQUIPMENT AND FITTINGS TO POLES
- AVAILABLE IN A VARIETY OF STRENGTH RATINGS AND GRADES
- CAN BE USED WITH ALL TYPES OF POLES, INCLUDING STEEL POLE, RCC, PSC AND WOODEN
- CAN BE MANUFACTURED FOR ALL POLE SIZES AND DIAMETERS
- CAN BE SUPPLIED WITH CROSSARMS AND FITTINGS
- PRODUCTS HOT DIP GALVANIZED AS PER BS EN ISO 1461 OR EQUIVALENT INTERNATIONAL STANDARDS
- PRODUCTS MANUFACTURED AS PER ALL ESTABLISHED INTERNATIONAL STANDARDS SUCH AS ASTM , ANSI, BSI (BS) , BS EN, ISO, IEC, EN, BIS (IS) , DIN, SABS (SANS), NFC, ETC.
- PRODUCTS CAN BE MANUFACTURED OR CUSTOMISED AS PER CLIENT REQUIREMENT
| PRODUCT CODE |
DIMENSION |
| POLE DIA |
FLAT SIZE |
BOLT SIZE |
NO. OF BOLTS |
| MM |
IN |
WIDTH (MM) |
THICKNESS (MM) |
MM |
|
| AO-PC-2A-01 |
127 - 178 |
'5 - 7 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-02 |
127 - 178 |
'5 - 7 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-EB-HK-03 |
127 - 178 |
'5 - 7 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-04 |
152 - 203 |
'6 - 8 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-05 |
152 - 203 |
'6 - 8 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-06 |
152 - 203 |
'6 - 8 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-07 |
178 - 229 |
'7 - 9 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-08 |
178 - 229 |
'7 - 9 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-09 |
178 - 229 |
'7 - 9 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-10 |
203 - 254 |
'8 - 10 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-11 |
203 - 254 |
'8 - 10 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-12 |
203 - 254 |
'8 - 10 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-13 |
229 - 279 |
'9 - 11 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-14 |
229 - 279 |
'9 - 11 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-15 |
229 - 279 |
'9 - 11 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-16 |
254 - 305 |
'10 - 12 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-17 |
254 - 305 |
'10 - 12 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-18 |
254 - 305 |
'10 - 12 |
64 |
6 / 8 |
16 / 20 |
2 |
| |
| AO-PC-2A-19 |
305 - 356 |
'12 - 14 |
35 |
6 |
16 / 20 |
2 |
| AO-PC-2A-20 |
305 - 356 |
'12 - 14 |
50 |
6 / 8 |
16 / 20 |
2 |
| AO-PC-2A-21 |
305 - 356 |
'12 - 14 |
64 |
6 / 8 |
16 / 20 |
2 |
