Bracket - D-Iron
- Manufactured from high strength galvanized steel
- Available in a variety of strength ratings and grades
- Can be supplied complete with spool or reel insulators, etc.
- Design and size can be modified and manufactured as per customer requirement and use
- Hot Dip Galvanized as per BS EN ISO 1461 or equivalent international standards
- Manufactured as per all established international standards such as ASTM , ANSI, BSI (BS) , BS EN, ISO, IEC, EN, BIS (IS) , DIN, SABS (SANS), NFC, ETC.
| PRODUCT CODE |
DIMENSIONS |
| |
WIDTH |
THICKNESS |
BOLT / COTTER SIZE |
| |
MM |
MM |
MM |
| AO-BRAC-DIR-01 |
30 |
5 |
12 |
| AO-BRAC-DIR-02 |
30 |
6 |
12 |
| AO-BRAC-DIR-03 |
32 |
5 |
12 / 16 |
| AO-BRAC-DIR-04 |
32 |
6 |
12 / 16 |
| AO-BRAC-DIR-05 |
32 |
8 |
12 / 16 |
| AO-BRAC-DIR-06 |
35 |
5 |
12 / 16 |
| AO-BRAC-DIR-07 |
35 |
6 |
12 / 16 |
| AO-BRAC-DIR-08 |
35 |
8 |
12 / 16 |
| AO-BRAC-DIR-09 |
40 |
5 |
16 |
| AO-BRAC-DIR-10 |
40 |
6 |
16 |
| AO-BRAC-DIR-11 |
40 |
8 |
16 |
| AO-BRAC-DIR-12 |
40 |
10 |
16 |
| AO-BRAC-DIR-13 |
50 |
6 |
16 |
| AO-BRAC-DIR-14 |
50 |
8 |
16 |
| AO-BRAC-DIR-15 |
50 |
10 |
16 |
